Hydrokinetic Turbines

Clean Power

Consist of simple, low-cost, vertical-axis hydrokinetic turbines that convert the kinetic energy in moving water into electricity. The versatile Evolution series ™ turbines are designed for deployment in rivers, canals and shallow water tidal sites. Solutions can be supplied for fixed/spanning structures, floating platforms, grid-tied systems and off-grid solutions.

Hydrokinetic solution consists of simple, low-cost, vertical axis hydrokinetic turbines that convert the kinetic energy in moving water into electricity.

The versatile Evolution series™ turbines are designed for deployment in rivers , canals and shallow water tidal sites.

Solutions can be applied for:

➣ Fixed/ spanning structures

➣ Floating platforms

➣ Grid-tie systems

➣ Off-grid solutions

Specifications

RATED POWER	5kW	10kW	25kW
RATED POWER SPEED	2.2 m/s*	2 m/s*	2.8m/s*
MAX POWER	7kW	13kW	32.5 kW
MAX WATER SPEED	2.5 m/s	2.2 m/s	3 m/s
START UP WATER SPEED	0.7 m/s	0.7 m/s	0.7 m/s
DIAMETER OF ROTOR	1.5 m (other sizes possible)*	3 m*	3 m standard*
HEIGHT OF ROTOR	1.5 m (other sizes possible)*	2 m*	2 m standard*
RPM AT RATED POWER	70 rpm	30 rpm	45 rpm
EXPORT VOLTAGE	3phase 380/400V, 50 Hz or 480, 60Hz	3phase 380/400V, 50 Hz or 480, 60Hz	3phase 380/400V, 50 Hz or 480, 60Hz
GRID STANDARDS	G98 or G99, VDE-AR-N 4105 VDE V 0124, EN 50549-1, VDE 0126/ UTE C 15/ VFR:2019, RD 1699/ RD 244/ UNE 206006/ UNE 206007-1, CEI 0-21, C10/11, NRS 097-2-1, TOR, EIFS 2018.2, IEC 62116, IEC 61727, IEC 60068, IEC 61683, EN 50530	G98 or G99, VDE-AR-N 4105 / VDE V 0124, EN 50549-1, VDE 0126/ UTE C 15 VFR:2019, RD 1699/ RD 244/ UNE 206006/ UNE 206007-1, CEI 0-21, C10/11, NRS 097-2-1, TOR, EIFS 2018.2, IEC 62116, IEC 61727, IEC 60068, IEC 61683, EN 50530	G98 or G99, VDE-AR-N 4105/ VDE V 0124, EN 50549-1, VDE 0126/ UTE C 15/ VFR:2019, RD 1699/ RD 244/ UNE 206006 / UNE 206007-1, CEI 0-21, C10/11, NRS 097-2-1, TOR, EIFS 2018.2, IEC 62116, IEC 61727, IEC 60068, IEC 61683, EN GH

*Other sizes and ratings are easily accommodated.
